CONSTRUCTION OF FLYOVER FROM INDORA SQUARE TO SHITALMATA CHOWK, NAGPUR IN THE STATE OF MAHARSHTRA
2024
On Going Project
India
20.124481 N, 79.118136 E
32 spans of 60m length and 12m wide deck (total 64 nos. of UBG3000) ,1 span of 60m length and flared carriageway from 12m to 17.367m wide deck (total 3 Nos. of UBG3000),1 span of 60m length and flared carriageway from 17.367m to 26.13m wide deck (total 5 nos. of UBG3000),2 spans of 90m length with 12m wide deck (total 4 nos. of UBG4000),1 span of 40m length with 12m wide deck (total 2 nos. of UBG3000)
UHPC U Beam- Composite with in-situ Deck Bridge System
RC Deck + UBG3000 girders for 60m and 40m spans and RC Deck + UBG4000 girders for 90m spans
Single RC Pier
Pile and Pile Cap
3-Lane Loading combination as per IRC
NATIONAL HIGHWAY AUTHORITY OF INDIA
Nagarjuna Construction Company Ltd.,‘NCC House’ Madhapur Hyderabad 500 081
Longspan Structures Pvt. Ltd.
VR2 INFRA SOLUTIONS PVT. LTD. Pragati Enclave, Miyapur, Hyderabad - 500 049.
